SA-V Change over valve

APPLICATION
For hydraulic systems, particularly dual-line centralized systems. For use SA-V as 3/2-way valve close outlet B

Product Characteristics
– Function 4/2-way
– Drive by direct-current geared motor
– Working pressure max. 400 bar

Working pressure max. 400 bar
Temperature range – 20° C up to + 80° C
Action time approx. 0.5 s
Angle of rotation 180°
Tightening torque 18 Nm
Torque 4 Nm
Operating voltage 110 – 127 and 200 – 240 V AC; 24 V DC
Cable gland M 25 x 1.5
Power consumption max. 42 W
Protection system IP 65
Installation position optional
Weight 13 kg
